24 Core Single Mode And Multimode Armored Fiber Optic Cable For Duct And Outdoor Use

Name: 24 Core Single Mode And Multimode Armored Fiber Optic Cable For Duct And Outdoor Use
Brand: TW-SCIE
Price: 1 USD

Wholesale 24 Core Single Mode And Multimode Armored Fiber Optic Cable For Duct And Outdoor Use from china suppliers

Brand Name : TW-SCIE

Model Number : GYTA/53

Certification : ROHS REACH SGS ISO

Place of Origin : DongGuan TW

Payment Terms : L/C, T/T, Western Union,MoneyGram

MOQ : Negotiable

Price : Negotiable

Supply Ability : 200km/Day

Delivery Time : one week

Packaging Details : Customize

Outer sheath material : PE

Outer Sheath Color : Black

Metallic Strengthen Member : Steel wire

Loose tube material : PBT or Jelly

Single Armour Material : Corrugated aluminium tape

Operating Temperature : -40 Degree ~ +60 Degree

Waterblocking Material : Water Blocking Tape or Filling Compound

Brand Name of Fiber : Corning, Yofc, Draka, Fujikura

Messenger Material : Steel Wires

installation methods : Aerial & Duct

Fiber type : G652D,single mode or multi mode,50/125,62.5/125,OM3

Type : Single Mode g652d,Outdoor Optical Cable Aerial

Fiber count : 2-24 cores,2-288 core

Contact Now

24 Core Aluminum GYTA Fiber Optic Cable for Duct Use

GYTA Sm Layer Stranded Fiber Optical Cable

Recommended laying methods
Aerial, Duct

Structure Characters
Metalic strengthen member(phosphated steel wire)

Double coated PE Crrugated steel tape under PE sheath

Properties
Corrugated aluminium tape providing an excellent moisture barrier

Appicable fieds
Long-distance communication, LAN
Moisture-proof and rodent-proof

Technical data:
Fiber Num.	Outer diameter (mm)	Weight (kg/km)	Min. Bending radius(mm)		Tension (N)		Crash loading (N/100mm)
Fiber Num.	Outer diameter (mm)	Weight (kg/km)	Static	Dynamic	Short term	Long term	Short term	Long term
2-30	9.8	95	10 times O. D.	20 times O. D.	1500	600	1000	300
32-36	10.3	115
38-60	10.7	115
62-72	11.3	140
74-96	12.9	175
98-120	14.4	210
122-144	15.8	245
146-216	16.3	260
218-240	19.5	345
242-288	21.7	415

24 Core Single Mode And Multimode Armored Fiber Optic Cable For Duct And Outdoor Use
